IONTECH® Instant Hot Water Sanitizable EDI
Hot water sanitization has been shown to be more effective than chemical sanitization for controlling microbial growth, primarily in the pharmaceutical and biotechnology industries and other applications where chemical-free, instant hot water sanitization is desired.
IONTECH modules are capable of continuous operation up to 140°F (60°C) allowing these modules to provide high quality water in higher temperature applications than typical CEDI, such as steam generation in power applications, without regeneration downtime.
IT-HI Series Features
- Hot Water Sanitizable at 185°F/85°C ± 5°C - Proven performance after 150+ sanitizations
- High Temperature Operation - Continuous operation up to 140°F (60°C) Feed Water
- No Chemicals Required - Generate mixed-bed quality deionized water without the use of chemicals
- Continuous Production - Instead of batch, with consistent quality and no regeneration downtime
- Leak-Free Guarantee - Double O-ring seal guarantees leak-free operation
- Superior Electrical Isolation - Enhanced safety for industrial applications
Typical Module Performance
Typical Recovery: 90-95%
Maximum Feed Pressure: 100 psi (6.9 bar)
DC Voltage: 0-600V
DC Amperage: 0-10A
Pressure Drop Range: 20-30 psi (1.4-2.1 bar)
Maximum Feed Temperature: 140°F (60°C)
Sanitization Temperature: 185°F (85°C)
Product Water Quality: <0.1 µS/cm
Available Models
IT-DS04HI-S
Flow: 1.0-3.0 gpm (0.22-0.67 m³/h)
Size: 300×605.5×318.5mm
IT-DS10HI-S
Flow: 2.5-7.5 gpm (0.55-1.65 m³/h)
Size: 388.6×605.5×318.5mm
IT-DS18HI-S
Flow: 4.5-13.5 gpm (1.1-3.1 m³/h)
Size: 505.7×605.5×318.5mm
IT-DS24HI-S
Flow: 6.3-18.8 gpm (1.4-4.2 m³/h)
Size: 593.9×605.5×318.5mm
IT-DS30HI-S
Flow: 7.5-22.5 gpm (1.65-5.11 m³/h)
Size: 696.5×605.5×318.5mm
IT-DS45HI-S
Flow: 11.3-33.8 gpm (2.55-7.67 m³/h)
Size: 907.3×605.5×318.5mm
Typical Applications
- • Power Industry
- • Hydrocarbon and Chemical Process Industry (HPI/CPI)
- • Food and Beverage
- • Semiconductor and Electronics Industry
- • Pharmaceutical
- • Laboratory
Quality Assurance Standards
- • CE marked for compliance with low voltage directive
- • Each module is factory tested to meet strict industry standards
- • Manufactured in ISO 9001 and ISO 14001 quality and environmental management system
- • Halal certified (IFANCA)
Get the Right Iontech Solution
Contact our team today to discuss your Iontech EDI requirements. We will help you select the right model based on your feedwater quality and production needs.
Our services include system design, installation, commissioning, and comprehensive maintenance contracts to ensure optimal performance.
