RO Membrane Systems
RO membranes are the heart of reverse osmosis systems, removing dissolved solids, contaminants, and impurities from water at the molecular level. High-rejection membranes ensure maximum purity and minimal waste.
PT Artha Inti Manunggal offers high-quality membranes for various applications including desalination, water reuse, and industrial process water.
Membrane Types
- • Thin Film Composite (TFC) Membranes
- • Cellulose Acetate (CA) Membranes
- • High Rejection Membranes
- • Low Energy Membranes
- • Fouling Resistant Membranes
- • High Silica Membranes
Applications
- • Desalination (Seawater & Brackish)
- • Water Reuse
- • Industrial Process Water
- • Drinking Water Treatment
- • Pharmaceutical Water
- • Food & Beverage Processing
- • Electronics Manufacturing
- • Boiler Feed Water
- • Wastewater Recovery
- • Laboratory Water
Key Features
- • High rejection rate (up to 99.5%)
- • Low energy consumption
- • Wide pH tolerance
- • High flow rates
- • Long service life
- • Stable performance
- • Resistant to fouling
- • Multiple sizes available
Membrane Specifications
- • Sizes: 4"x40", 8"x40", 8"x60"
- • Material: Polyamide Thin Film Composite
- • Operating Pressure: 150-400 psi
- • Temperature: 1-45°C
- • pH Range: 2-11
- • Recovery: 8-15%
- • Rejection: 95-99.5%
Membrane Element Models
Membrane Elements
| Model | Capacity | Recovery Rate | Operating Pressure | Power | Dimensions |
|---|---|---|---|---|---|
| LM8040-SW | 7,000 GPD (26 m³/d) | 8% | 800 psi (5.5 MPa) | 99.80% rejection | 400 ft² (37.2 m²) |
| LM8040-SWLE | 8,000 GPD (30 m³/d) | 8% | 800 psi (5.5 MPa) | 99.70% rejection | 400 ft² (37.2 m²) |
| LM8040-SWXLE | 9,000 GPD (34 m³/d) | 8% | 800 psi (5.5 MPa) | 99.60% rejection | 400 ft² (37.2 m²) |
| LM8040-BW | 13,500 GPD (50 m³/d) | 15% | 225 psi (1.55 MPa) | 99.40% rejection | 400 ft² (37.2 m²) |
| LM8040-BWFR | 10,500 GPD (40 m³/d) | 15% | 225 psi (1.55 MPa) | 99.50% rejection (Fouling Resistant) | 400 ft² (37.2 m²) |
| LM8040-BWFR/34 | 10,500 GPD (40 m³/d) | 15% | 225 psi (1.55 MPa) | 99.50% rejection (Fouling Resistant) | 400 ft² (37.2 m²) |
| LM8040-XFR | 12,000 GPD (45 m³/d) | 15% | 225 psi (1.55 MPa) | 99.50% rejection | 400 ft² (41 m²) |
| LM8040-NF90 | 7,500-10,000 GPD (28-38 m³/d) | 15% | 70 psi (0.48 MPa) | 85-95% NaCl / 98% MgSO4 rejection | 400 ft² (37.2 m²) |
| LM8040-NF200 | 11,000-12,000 GPD (42-45 m³/d) | 15% | 70 psi (0.48 MPa) | 35-60% NaCl / 98% MgSO4 rejection | 400 ft² (37.2 m²) |
Membrane Housings
We also provide stainless steel membrane housings compatible with all standard RO membranes.
- • Material: SS304, SS316, SS316L
- • Sizes: 4", 8" diameter
- • End Entry and Side Entry options
- • Hydraulically tested
- • ASME code optional
- • Various port configurations
Experienced in RO Membrane Systems
Artha Inti provides premium RO membranes for various industries.
Our team has extensive experience in membrane selection, installation, and replacement.
Get the Right RO Membrane Solution
PT. Artha Inti Manunggal specializes in RO membrane systems tailored to meet your specific requirements.
We know you need solutions, not just a filter.
Once we understand your situation we'll provide the best solution to keep your water quality high. Our treatments are efficient and accurate, avoiding the wrong chemicals that could make things worse. Our expert support team is happy to discuss with you and find the optimal answer to your problem.
