Carbon Filter Systems
Granular Activated Carbon (GAC) is designed for the reduction of chlorine, taste, odor, and dissolved organic material from municipal and industrial water supplies. High efficiency, in-depth filter system using a layered media bed of silica sand and anthracite.
PT Artha Inti Manunggal offers comprehensive carbon filter solutions for commercial and industrial applications.
Applications
- • Chlorine removal
- • Taste and odor reduction
- • Dissolved organic material removal
- • Municipal water treatment
- • Industrial water treatment
- • Pre-treatment for RO systems
- • Beverage and food processing
- • Pharmaceutical water treatment
Standard Features
- • Backwash Water Supply Pumps
- • RO Low Pressure Lockout Switch
- • Motorized Stagers for Automatic Operation
- • Timer Initiated Backwash Cycle
- • Aquamatic Diaphragm Style Control Valves
- • Hydraulically Operated
- • Stainless Steel Pipe
Options Available
- • Skid mounted, pre-piped, pre-wired systems
- • Multi-tank system configurations (twin, triple, quad)
- • Inlet/Outlet pressure gauges and sample valves
- • Differential pressure switch backwash cycle
- • Custom tank sizes
- • Various media options
Materials of Construction
- • Control Valve: Manual multi-port Valve
- • Automatic Top/Side Mount Backwash Flow Controller
- • Resin Tanks: Fiberglass reinforced polyethylene (FRP)
- • Internal Distributors: PVC/ABS/PP
- • Housing: Carbon steel with epoxy coating
Operating Parameters
- • Inlet Pressure: 30-100 psig
- • Electrical: 220VAC, 1-Phase, 60 Hz
- • Operating Temperature: 4-40°C
- • pH Range: 6.5-8.5
FR Series Specifications
| Model | Capacity | Recovery Rate | Operating Pressure | Power | Dimensions |
|---|---|---|---|---|---|
| FR-1054 | 0.6-1.5 m³/h | - | 30-100 psig | 50 litre | 254 x 1380 mm |
| FR-1354 | 2.0-2.5 m³/h | - | 30-100 psig | 75 litre | 330 x 1370 mm |
| FR-1665 | 3.0-4.5 m³/h | - | 30-100 psig | 150 litre | 406 x 1630 mm |
| FR-1865 | 4.5-5.0 m³/h | - | 30-100 psig | 175 litre | 457 x 1815 mm |
| FR-2162 | 5.0-6.0 m³/h | - | 30-100 psig | 225 litre | 533 x 1755 mm |
| FR-2472 | 6.0-8.0 m³/h | - | 30-100 psig | 325 litre | 610 x 1920 mm |
| FR-3072 | 8.0-12 m³/h | - | 30-100 psig | 500 litre | 762 x 1930 mm |
| FR-3672 | 13-16 m³/h | - | 30-100 psig | 775 litre | 914 x 2180 mm |
Experienced in Carbon Filter Systems
Artha Inti offers carbon filter solutions for various industries requiring clean, great-tasting water.
Our team has successfully installed and maintained carbon filter systems across multiple sectors.
Get the Right Carbon Filter Solution
PT. Artha Inti Manunggal specializes in carbon filter systems tailored to meet your specific requirements.
We know you need solutions, not just a filter.
Once we understand your situation we'll provide the best solution to keep your water quality high. Our treatments are efficient and accurate, avoiding the wrong chemicals that could make things worse. Our expert support team is happy to discuss with you and find the optimal answer to your problem.
